AT A GLANCE
Camera effective pixels Approx. 20.4 megapixels
Sensor size / Total pixels / Filter 4/3-type Back-illuminated (BSI) CMOS image sensor / Approx. 26.5 total megapixels / Primary color filter
AR (Anti Reflection) coating Yes
Lens LEICA DC VARIO-SUMMILUX 11 elements in 8 groups
     (5 aspherical lenses / 8 aspherical surfaces)
Aperture F1.7 - 2.8 / 9 Diaphragm Blades (F1.7 - 16.0 (W), F2.8 - 16.0 (T))
Optical zoom 3.1x
Focal length f = 10.9 - 34mm
           (24 - 75mm in 35mm equivalent in 4:3, 3:2, 16:9)
           (28 - 88mm in 35mm equivalent in 1:1)
Crop Zoom Still image / Motion picture
Image stabilizer POWER O.I.S.
Latitude 13+ stops (Sensor output is 60fps or less)
        12+ stops (Sensor output is 61fps or higher) (V-Log)Â
Recording file format JPEG (DCF/Exif3.0) / RAW / HEIF
File size (pixels)
- 4:35200x3904 (L) / 3744x2808 (M) / 2624x1968 (S) / 1920x1440 (XS)
- 3:25408x3608 (L) / 3888x2592 (M) / 2736x1824 (S) / 1920x1280 (XS)
- 16:95664x3192 (L) / 4096x2304 (M) / 2832x1592 (S) / 1920x1080 (XS)
- 1:13904x3904 (L) / 2816x2816 (M) / 1968x1968 (S) / 1440x1440 (XS)
Image quality Fine / Standard
HEIF format HDR (HLG) / SDR
Color spaces RGB / AdobeRGB
Recording file format MOV: H.264/MPEG-4 AVC, H.265/HEVC
                  MP4: H.264/MPEG-4 AVC, H.265/HEVC
                  MP4(Lite): H.265/HEVC
Viewfinder 0.39" OLED LVF (Live View Finder) (Approx. 2,360k dots), Field of view: Approx. 100%
         Magnification: Approx. 0.74x (35mm camera equivalent), Eye point: Approx. 20mm from eyepiece lens
Rear monitor 7.6cm (3.0") free-angle TFT screen LCD display (Approx. 1,840k dots)
            Static touch control
            Field of view: Approx. 100%
Focus Type Phase Detection AF system (779-point) / Contrast AF system (315-area)
DFD technology Yes
Focusing area Normal: 50 cm - infinity
             AF Macro / MF / Intelligent Auto / Motion Picture: Wide 3 cm - infinity / Tele 30 cm - infinity
Focus mode  AFS (Single) / AFC (Continuous) / MF
AF mode  Tracking / Full Area AF / Zone (Horizontal/Vertical) / Zone / 1-Area+ / 1-Area / Pinpoint
AF detective range  EV -5 - 18 (F1.7, ISO100, AFS)
AF custom setting  AF Sensitivity, AF Area Switching Sensitivity, Moving Object Prediction
AF assist light  Yes (On / Off)
AF lock  Set the Fn button in custom menu to AF lock
Focus ring control Nonlinear / Linear (120°/ 150°/ 180°/ 210°/ 240°/ 270°/ 300°/ 330°/ 360°/ 720°/ 1080°/ Maximum)Â
Light metering system 1,728-zone multi-pattern sensing system
Light metering Multiple / Center Weighted / Spot / Highlight Weighted
Recording mode Mode dialProgram AE (P) / Aperture Priority AE (A) / Shutter Priority AE (S) / Manual Exposure (M) / Custom 1, 2, 3, 4, 5 / Intelligent Auto
Photo/Video/S&Q switch Photo Mode / Video Mode / Slow&Quick Mode
Custom mode The settings can be registered for each of the photo, video, and S&Q modes.
White balance White balanceAWB / AWBc / AWBw / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2, 3, 4 / Color temperature setting 1, 2, 3, 4
            White balance adjustmentBlue/Amber bias, Magenta/Green bias
             Color temperature setting2500-10000K in 100K
Self timer 10sec, 3 images / 2sec / 10sec / Custom Time
AE bracket 3, 5, 7 images in 1/3, 2/3 or 1 EV step, Max. +/-3 EV
Aperture bracket 3, 5 or all positions in 1 EV step
Focus bracket Yes
White balance bracket 3 images in blue/amber axis or in magenta/green axis, color temperature setting
Flash type Sold separately
Flash mode Auto* / Auto/Red-eye Reduction* / Forced On / Forced On/Red-eye Reduction / Slow Sync. / Slow Sync./Red-eye Reduction / Forced Off *For iA only.
Flash output adjustment 1/3EV step ±3EV
Flash synchronization 1st curtain sync, 2nd curtain sync.
USB USB Type-C® (USB 10Gbps)
     USB power supply, USB power charging
     UVC support
Build-in microphone Stereo
                 Wind Noise Canceller: OFF / Standard / High
External microphone / External audio device input   φ3.5mm for external microphone / external audio device
                                           MIC (Plug-in Power) / MIC / LINE
                                           Wind Cut*: OFF / Low / Standard / High *When a Φ3.5mm microphone is attached.
                                           Special Mic*: Stereo / Shotgun *When the DMW-MS2 (sold separately) is attached.
Speaker Monaural
Recording media SD Memory Card / SDHC Memory Card* / SDXC Memory Card*
              *Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards.
Wi-Fi  2.4GHz bands (AP) (IEEE802.11b/g/n)
      5GHz bands (AP) (IEEE 802.11a/n/ac)
      WPA / WPA2 / WPA3
      Infrastructure Mode
Bluetooth Bluetooth® v5.0 (Bluetooth Low Energy (BLE))
Power Li-ion Battery Pack (7.2V, 2200mAh, 16 Wh) (Included)
Battery life (Approx.) Approx. 420 images (rear monitor), 410 images (LVF), 1,000 images (Power Save LVF mode*) with DMW-BLK22
         *Using a Nextorage SDXC memory card. Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec.
Continuous recordable time (Motion picture)Â MP4 [4K/60p]: Approx. 100 min
                                    MP4 [FHD/30p]: Approx. 140 min
Actual recordable time (Motion picture)Â MP4 [4K/60p]: Approx. 50 min
                                MP4 [FHD/30p]: Approx. 70 min
Dimensions (W x H x D)Â Approx. 127.1 x 73.9 x 66.9 mm / 5.01 x 2.91 x 2.64 inchÂ
Weight Approx. 508 g / 1.12 lb (Body, Battery, SD Memory Card, Hot Shoe Cover) (excluding body cap)
       Approx. 425 g / 0.94 lb (Body, Hot Shoe Cover) (excluding body cap)
