Key Features

• Traditional Porro Prism Design
• Antireflection Multicoated Optics
• Wide 61.4 Apparent Angle of View
• Large Center Focusing Wheel
• Turn-and-Slide Eyecups

Optical Performance

• Traditional Porro prism light path produces a rich depth of field, allowing the user to discern the relative distances between objects in the view
• Anti-reflection multicoated optics produce neutral and accurate color fidelity and improve contrast and image brightness
• 61.4 apparent angle of view reduces the appearance of visible hand shake, which is especially common with higher-power optics

Use and Handling

• Large slip-resistant center focus wheel is easy to manipulate, even while wearing gloves
• Right-eye dioptric correction compensates for individual user's optical prescription for clearer and sharper views
• Turn-and-slide eyecups for comfortable use with or without eyewear

Prism Type  Porro

Magnification  10x

Objective Lens Diameter  42 mm

Angle of View  6.8° (Actual)
                        61.4° (Apparent)

Field of View  356' @ 1000 yd / 118.2 m @ 1000 m

Exit Pupil Diameter 4.2  mm

Minimum Focus Distance  16.4' / 5 m

Eye Relief  16.1 mm

Interpupillary Adjustment  No

Diopter Adjustment  No

Focus Type  Center

Fogproof  No

Environmental Resistance  No

Dimensions  7.6 x 5.9" / 19.3 x 15 cm

Weight  27.9 oz / 791 g
