2.7-inch LCD monitor with the Outdoor View Setting mode
The WG-90 comes equipped with a 2.7-inch LCD monitor with horizontally extended 16:9 proportions and approximately 230,000 dots. The monitor’s AR (Anti-Reflection) coating minimizes annoying glare and reflections to assure a sharp, clear on-screen image even in the harsh sunshine often encountered during outdoor shooting. The Outdoor View Setting mode automatically optimizes the monitor’s brightness level for a given lighting condition to improve the visibility of the on-screen image.
* Image of the monitor in sunny conditions. Monitor display is artist’s conception.
Underwater shooting mode
Specifically designed for underwater photography, the Underwater and Underwater Movie shooting modes are programmed to optimize colour and contrast, based on the data of images captured under the water. These modes deliver sharp, true-to-life images by enhancing shades of red which are lost in underwater photography, while effectively compensating for the loss of contrast caused by the diffusion of light in water. In the Underwater mode, the Flash Off + Flash On option allows the user to consecutively capture two images with a single shutter release — one without flash and another with flash.

 5X optical zoom lens with a 28mm wide-angle coverage
The WG-90 features a high-performance, five-times optical zoom lens with a focal-length coverage from 5mm to 25mm (equivalent to approx. 28mm to 140mm in the 35mm format) to accommodate a wide range of scenes and subjects, including sweeping landscapes. It also provides other convenient shooting functions, such as a macro mode to capture dramatic close- up images from a minimum focusing distance of a mere one centimeter; an Intelligent Zoom function to extend the zoom range to approximately 36 times (equivalent to 1008mm in the 35mm format)**** for super-high-magnification telephotography without compromising image quality; and an interval shooting mode that comes in handy for fixed point photography.
**** This function is available when the recorded size of 640 is selected.
Triple anti-shake protection to prevent blurred images in all applications
(1) Pixel Track SR mechanism
When recording still images, this advanced shake-reduction mechanism effectively compensates for camera shake by digitally processing affected images.
(2) Digital SR mode
When the camera detects low-lighting conditions in still-image shooting, this mode automatically raises the sensitivity up to as high as ISO 6400, making it possible to use a higher shutter speed and effectively minimize the adverse effect of camera shake and subject shake when dealing with poor lighting conditions.
(3) Movie SR mode
During movie recording, this mode effectively compensates for the misalignment of images caused by camera shake through the use of exclusive software to produce beautiful, blur-free movie clips.
4 RICA_01.2024

Full HD movie recording for extended shooting of high-quality movies
The WG-90 provides Full HD movie recording employing the H.264 recording format. Users can capture high-quality, extended movie clips (1920 x 1080 pixels, 16:9 proportions) at a frame rate of 30 frames per second. To add some creative touches to movie recording, they also feature a high-speed camera function***** for slow-motion playback of captured movie clips, and an interval movie function. A micro-HDMI terminal (Type D) is also provided on the camera body for simultaneous output of Full HD movie clips and sound to external audio-visual devices.
***** When this function is selected, the recorded size is fixed at 1280 x 720 pixels.
Other Features
• Macro stand (included) to maintain a minimum focusing distance of one centimeter to the subject during extended observation and shooting of macro images
• Auto Picture mode to automatically select the most appropriate shooting mode from 16 different scene modes
• High-speed Face Detection function to capture as many as 32 faces in focus in approximately 0.03 seconds (minimum); Smile Capture function to automatically release the shutter when the subject’s smile is detected
• Outdoor-friendly Style Watch function to display the time on the LCD monitor, using an extended push of the OK button when the camera’s power is turned off
• Delay-free, pushbutton start of the playback mode, using an extended push of the playback button
• Auto Picture mode to automatically select the most appropriate shooting mode from 16 different scene modes

Lens
PENTAX lens, 11 elements in 9 groups (5 aspherical elements)
Focal Length  5 - 25 mm  (in 35mm format equivalent)  Approx. 28 - 140mm
Maximum Aperture  F3.5(W) - F5.5(T)
Zoom  Optical Zoom  5X
Digital Zoom  approx. 7.2X
Intelligent Zoom  approx. 7.5X at 7M, approx. 36X at 640 (including optical zoom)
Motion Blur Reduction  Still
Pixel Track SR Hi-sensitivity anti-shake mode (Digital SR)
Movie
Movie shake reduction mode (Movie SR)
Focus  Type  9-point AF, Spot AF, Auto tracking AF
Focus Range  Standard: 0.5m - infinity / 1.64ft. - infinity (entire zoom range)
(From lens face)
Macro: 0.1 - 0.6m / 0.33 - 1.97ft. (entire zoom range)
1cm Macro: 0.01 - 0.3m / 0.03 - 0.98ft. (middle zoom position)
Infinity-landscape, Pan Focus, Manual Focus: available
Number of Effective pixels  Approx. 16 megapixels
Image Sensor  1/2.3" CMOS

Image Tone  Bright, Natural, Vibrant, Slide Film, Monochrome, Cross Processing
Number of Recorded pixels
Still
16M, 12M(1:1), 12M(16:9), 7M, 5M(16:9), 5M, 4M(16:9), 3M, 2M(16:9), 1024, 640
Movie
1920, 1280
Sensitivity (Standard Output Sensitivity)
AUTO, Manual (ISO 125 - 6400)
White Balance
Auto, Daylight, Shade, Tungsten light, Fluorescent light (D: Daylight Colour, N: Daylight White, W:White Light), Manual
Display
2.7" Wide LCD, approx. 230K dots, AR Coating (Cover only)
Exposure Control
Metering System
Multi-segment metering, Center-weighted metering, Spot metering
Exposure Compensation
± 2EV (1/3EV steps)
Scene modes
Auto Picture, Program, HDR, Handheld Night Snap, Movie, High Speed Movie, Digital Microscope, Landscape, Flower, Portrait, Underwater, Underwater Movie, Interval Shot, Interval Movie, Surf & Snow, Kids, Pet, Sport, Night Scene, Night Scene Portrait, Fireworks, Food, Digital SR, Report, Green
Face detection
Face Detection AF&AE is available for all modes up to 32 faces. Smile Capture, Self-portrait Assist, Self-portrait Assist + Smile Capture, Blink Detection
Pet detection
Detect up to 1 pet's face(auto)
Playback modes
Slideshow, Image Rotation, Small Face Filter, Ink Rubbing Filter, Collage, Digital Filter (B&W / Sepia, Toy Camera, Retro, Colour, Extract Colour, Colour Emphasis, High Contrast, Starburst, Soft, Fish-eye, Brightness, Miniature), HDR Filter, Original Frame, Movie Edit, Red-eye Edit, Resize, Cropping, Image Copy, Protect, Start-up Screen
Shutter Speed
1/4000 - 1/4sec. (Mechanical and electronic shutter), 4sec at most. (Night Scene mode setting)
Built-in flash
Modes
Flash-on and Flash-off modes. "Red-eye" compensation function employs a pre-discharge.
Flash Range
Wide: approx. 0.2 - 5.5m / 0.66 - 18 ft. (ISO Auto)
(Except Ring Light Mode)
Tele: approx. 0.2 - 3.5m / 0.66 - 11 ft. (ISO Auto)
Drive Modes
One shot, Self-timer, Continuous Shooting, Burst Shooting, Remote Control, Auto Bracketing
Storage Media
Built-in Memory (approx. 68MB), SD/SDHC/SDXC Memory Card
Power Source
Rechargeable D-LI92 lithium-ion battery
Battery life
Still*: approx. 300 shots (Rechargeable Lithium-ion battery)
Playback**: approx. 260 min. (Rechargeable Lithium-ion battery)
Interfaces
USB2.0(Micro-B), HDMI output terminal (Type D)
Waterproof / Dustproof
Equivalent to JIS Class 8 waterproof and JIS Class 6 dustproof capabilities
Dimensions
Approx. 122.5 (W) x 61.5 (H) x 29.5 (D)mm /4.8 (W) x 2.4 (H) x 1.2 (D) inches (including lens depth)
Weight
With battery & SD card
Approx. 194g / 6.8 oz. (loaded and ready)
Body only
Approx. 173g / 6.1 oz. (without battery and SD memory card)
