AT A GLANCE

• Type Digital Single Lens Mirrorless camera
• Recording media "SD Memory Card / SDHC Memory Card* / SDXC Memory Card* *Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards."
• Lens mount Micro Four Thirds mount
• Image Sensor Live MOS sensor (17.3 x 13.0 mm)
• Camera effective pixels / Total pixels 10.28 megapixels / 11.93 megapixels
• Aspect ratio / Color filter 4:3 / Primary color filter
• Still Image Recording file format: JPEG (DCF, Exif 2.31) *Still image shooting is available only when using the LUMIX Tether software.
• Aspect ratio 4:3
• File size (Pixels) 3680x2760(L) / 2592x1944(M) / 1824x1368(S)
• Image quality Fine / Standard
• Color space sRGB
• Motion Picture Recording file format: "MOV: H.264/MPEG-4 AVC, H.265/HEVC (Audio format: LPCM (2ch 48kHz/16-bit, 48kHz/24-bit*, 96kHz/24-bit*)) *When attaching DMW-XLR1 (sold separately). MP4: H.264/MPEG-4 AVC, H.265/HEVC (Audio format: AAC (2ch))"
• System frequency 59.94Hz / 50.00Hz / 24.00Hz
• DFD technology: Yes
• Focus mode: AF / MF
• AF mode: Motion picture: Auto Detection (Face, Eye, Body, Animal) / Tracking / 225-Area / Zone (Oval) / 1-Area, Still image: Auto Detection (Face, Eye, Body, Animal) / 225-Area /1-Area *Still image shooting is available only when using the LUMIX Tether software."
• AF detective range EV -6 - 20 (F1.4, ISO100 equivalent, AF (Still image))
• AF custom setting (Motion picture) AF Speed, AF Sensitivity
• AF lock: Set the Fn button in custom menu to AF lock
• Others: AF-ON, Continuous AF, AF+MF, MF Guide, MF Assist, Focus Peaking, Focus Ring Lock, 1-Area AF Moving Speed, Lens Focus Resume
• Light metering system: 1,728-zone multi-pattern sensing system
• Light metering mode: Multiple / Center Weighted / Spot / Highlight Weighted
• Metering range: EV0-18 (F2.0 lens, ISO100 equivalent)
• Exposure mode: Program AE / Aperture Priority AE / Shutter Priority AE / Manual Exposure
• ISO sensitivity (Standard output sensitivity): Auto / 80* / 100* / 160 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 / 51200 / 102400* / 204800* (Changeable to 1/3 EV step) *Extended ISO
• Exposure compensation: "Motion picture: 1/3 EV step ±3EV, Still image: 1/3 EV step ±5EV *Still image shooting is available only when using the LUMIX Tether software."
• White balance: AWB / AWBc / AWBw / Daylight / Cloudy / Shade / Incandescent / White Set 1, 2, 3, 4 / Color temperature setting 1, 2, 3, 4
• White balance adjustment: Blue/Amber bias, Magenta/Green bias
• Color temperature setting: 2500-10000K in 100K
• Direct power supply: "AC Adaptor (12V, 3A) (bundled), Li-ion Battery Pack (7.28V) (sold separately), PoE+ (IEEE802.3at compliant) (sold separately) "
• Continuous recordable time (Motion picture)**: "MP4 [4K/60p]: Approx. 270 min, MP4 [FHD/60p]: Approx. 300 min *When using H-ES12060 and AG-VBR59 (sold separately). When the battery is fully charged. MP4 [4K/60p]: Approx. 420 min, MP4 [FHD/60p]: Approx. 480 min *When using H-ES12060 and AG-VBR89 (sold separately). When the battery is fully charged. MP4 [4K/60p]: Approx. 560 min, MP4 [FHD/60p]: Approx. 640 min *When using H-ES12060 and AG-VBR118 (sold separately). When the battery is fully charged."
• Dimensions (W x H x D) Approx. 93.0 x 93.0 x 78.0 mm / 3.66 x 3.66 x 3.07 inch (excluding protrusions)
• Weight Approx. 545g / 1.2 lb (Body only)
• Operating temperature**** -10oC to 40oC (14oF to 104oF)
• Operating humidity 10%RH to 80％RH
• Software "LUMIX Tether ・ This software is used to control a Panasonic digital camera from a PC. It allows you to change various settings of the camera, perform remote recording, and save remotely recorded images to the PC. Check the site below to download and install the software. http://panasonic.jp/support/global/cs/soft/download/d_lumixtether.html (For Windows / Mac)"
• Standard accessories: "AC Adaptor, AC Cable, Cable Lock Band, Body Cap, Hot Shoe Cover, AUDIO Terminal Cover, DC IN Terminal Cover, BNC Terminal Cover, HDMI Terminal Cover, REMOTE Terminal Cover ・ The DC-BGGH1 Operating Instructions for advanced features is available for downloaded at Panasonic LUMIX Customer Support Site using PC, smartphone or tablet connected to the Internet."
